Forster Co-Ax XL Single Stage Reloading Press
$1,199.99
The Forster Co-Ax XL Single Stage Reloading Press is a heavy-duty steel weldment press designed to accept both 1 1/4″ and 7/8″ dies. It features a floating quick-change die station, a universal shell holder for perfect case centering, and a spent primer catch system. Built for precision and durability, it offers smooth operation with ball bearings in the handle connection and includes a light for better visibility. This press is ideal for a wide range of calibers but does not include a priming system.
The Forster Co-Ax XL Single Stage Press is made to accept 1″ 1/4″ Dies as well as 7/8″ dies (adaptor lock ring required (2) included with the press). The Press was designed with ELR Shooters in mind and is built with the same float advantage, quick die change and precision of the standard Co-Ax. The steel weldment and 13″ handle give it unrivaled rigidity and leverage. The addition of ball bearings to the handle improves operation and makes for one of the smoothest reloading experiences ever. If doing something that does not require as much leverage, our Short Handle will adapt into this press.
Features
- Accepts both 1 1/4″ and 7/8″ Dies
- Made from a steel weldment as opposed to Cast Iron
- Accepts a wider range of calibers
- No priming system
- A light has been added
- Ball bearings in the handle-frame connection
- Spent primer catch system
- Quick die change
- Floating jaw system
- Mechanical advantage
Note: Forster is in the process of having 50 BMG Dies available (along with 375 CheyTac, 408 CheyTac, and 375 EnABELR Dies). The standard shell holder is machined to be .125″ thick (same as all standard shell holders). Most 50 BMG Dies are made to work with thicker shell holders and if used in the press will need to be adjusted accordingly.
Made In United States of America
Specifications
Product Information
| Frame Material | Steel |
| Press Type | Single Stage |
| Priming Feature | No |
| Handle Location | Top Center |
| Number of Mounting Holes | 2 |
| Spent Primer Collection System | Yes |
| Die Size Accepted | 1-1/4″-12 without Bushing, 7/8″-14 with Bushing |
| Frame Design | O-Frame |
| Country of Origin | United States of America |
Delivery Information
| Shipping Weight | 35.240 Pounds |
| Press Type: | Single Stage |
|---|
